Case Studies

220KV Devikot Substation

Company: Gamesa Renewable Pvt. Ltd.

Developer: Rajgarh Windpark Pvt. Ltd.

Location: Devikot, Jaisalmer, Rajasthan

Scope: 220KV, 3X100MVA Substation, 41KM 220KV DC Zebra line

WTG Foundations: 37 nos. of 2 MW Gamesa make WTG

220KV Amrapur Substation

Company: Gamesa Renewable Pvt. Ltd.

Developer: Kintech Santalpur Windpark Pvt. Ltd.

Location: Amarapar, Patan, Gujarat

Scope: 220KV, 3X100MVA Substation, 86KM 220KV DC Zebra (AL59) line

220KV Asoj Substation

Company: Gujarat Energy Transmission Corporation Ltd.

Developer: Gujarat Windpark Pvt. Ltd.

Location: Asoj, Gujarat

Scope: Supply, Erection, Testing & Commissioning for 220/66KV system at existing 400KV Asoj Substation

Details: 400/220KV ICTs, control wiring, earthing, lighting installation

220KV Vandhiya Substation

Company: Vestas Wind Technology Pvt. Ltd.

Developer: Vandhiya & Jangi Windpark Pvt. Ltd.

Location: Vandhiya & Jangi, Kutch, Gujarat

Scope: 220/33KV, 2X100MVA Substation

WTG Foundations: 14 × 1.65MW + 97 × 1.8MW Vestas WTG

33KV USS: Road & Platform

132KV Ludarva Substation

Company: Veer Energy Infrastructure Pvt. Ltd.

Developer: Ludarva Windpark Pvt. Ltd.

Location: Village Ludarva, Dist. Jaisalmer, Rajasthan

Scope: Construction of 132KV, 2X50MVA Substation

WTG Foundations: 33KV USS, 33KV Line, Road & Platform

132KV Shikarpur Substation

Company: Vestas Wind Technology India (P) Ltd.

Developer: Shikarpur Windpark Pvt. Ltd.

Location: Village Shikarpur, Dist. Kutch, Gujarat

Scope: Construction of 132KV, 1X30MVA, 1X70MVA Substation

WTG Foundations: 1x0.95MW, 25x0.75MW NEG Micon, 23x1.65MW, 18x1.8MW Vestas

66KV Koblavadar Substation

Company: Powerica Limited

Developer: Koblavadar Windpark Pvt. Ltd.

Location: Village Goinj, Dist. Jamnagar

Scope: Construction of 66/33KV, 1X30MVA Substation, 10 Nos. 33KV Unit Substation, 11km 33KV line

WTG Foundations: 10 Nos. of 2.0MW Vestas make WTG

66KV Motagunda Substation

Company: Elecon Windfarm Developers Ltd.

Developer: Motagunda Windpark Pvt. Ltd.

Location: Village Motagunda, Dist. Jamnagar, Gujarat

Scope: Construction of 66/33KV, 2X25/30MVA Substation, 33KV Unit Substation

WTG Foundations: 31x0.85MW Gamesa, 2x0.225MW GWL, 28x2.1MW Suzlon, 2x1.5MW PSWL, 1x1.25MW PSWL, 2x2MW Gamesa, 2x1.05MW PSWL

132KV Pratapgarh Substation

Company: Welspun Energy Private Limited

Developer: Pratapgarh Windpark Pvt. Ltd.

Location: Village Pratapgarh, Rajasthan

Scope: Construction of 132/33KV, 2X75MVA Substation

132KV Bhomiyavadar Substation

Company: Gamesa Renewable Pvt. Ltd.

Developer: Bhomiyavadar Windpark Pvt. Ltd.

Location: Village Mota Gunda, Dist. Jamnagar

Scope: Construction of 132KV, 2X50MVA Substation, 28 Nos. 33KV Unit Substation, 33KV Internal & External line

WTG Foundations: 28 Nos. of 2.1MW Suzlon make WTG

66KV Maliya Substation

Company: Gamesa Renewable Pvt. Ltd.

Developer: Maliya Windpark Pvt. Ltd.

Location: Village Maliya, Dist. Morbi, Gujarat

Scope: Construction of 66/33KV, 2X25/30MVA Substation and 2 nos. 66KV GETCO feeder bays at GETCO Jetpar Substation

Torrent Power LTD

Installation: 33KV, 2x30MVA Geetabaug Substation at Ahmedabad in year 2009.

Civil Work: 132 KV Prahladnagar, Ahmedabad – Year 2012.

33 KV GMDC, University ground, Ahmedabad – Year 2013.

33 KV Civil Hospital, Shahibaug, Ahmedabad – Year 2014.
